TEKLA GLOBAL BIM AWARDS 2020

The project Water Street Bridge in Canary Wharf has been showered in awards and accolades over the past few years, and now it's fourth major award is within grasp, and we need your help!

The project has been automatically entered into the biannual "Tekla Global BIM awards 2020" having won the UK Tekla BIM Award in 2019. In the Infrastructure category, Water Street Bridge is competing with 18 projects from across the world, as the UK representative of BIM excellence.

The winning project of their category is determined by the voting public, and that's where you come in. You can cast your vote from now until the end of the month, but don't delay!

Please share the below link on your social media accounts or with family, friends and colleagues to help us secure this prestigious award.

Share this link: https://bit.ly/3hdPpwZ

What makes Water Street Bridge such ground-breaking project worthy of Tekla Global award?

Video link: https://www.youtube.com/watch?v=yL1nhSvfnu4

The Water Street bridge is a road and pedestrian link between Montgomery Square within the existing Canary Wharf estate and the new Wood Wharf development, but this is no ordinary bridge. The Project is a bespoke semi-submerged, single-leaf bascule bridge, meaning it required the construction of two semi-submerged abutments and a marine causeway. The most technically challenging abutment on the east side was constructed above water level and lowered 4-5 meters below the dock level. Temporary works were designed and delivered by Kilnbridge.

The project required the combined expertise of our Design and Engineering Hub, Civil Engineering, Concrete Cutting, Fabrication and Fire protection business units. Our efforts were guided by the application of our advanced BIM capabilities to accomplish this major feat of engineering.

The Project has been recognised over the last few years by;

The use of BIM and Tekla

Given the hybrid nature of the structure, combining insitu concrete, precast concrete, finished concrete and temporary works elements, co-ordination and development of the solution within the limited time frame was aided immeasurably by the use of BIM and notably Tekla. An animation of the construction programme based on the model was produced to provide a visual tool for the operatives during the inductions and site briefings to ensure that all were aware of the sequence of works and key deliverables.

The production capabilities and the ease of change control allowed within Tekla was exemplified when only two weeks prior to a key element of the works being constructed, the permanent works engineer realised that they had not correctly accounted for the loading from a ship impact and required substantial changes in the reinforcement. This was incorporated within the model, clash checked and the corresponding drawings and schedules generated within only two days to enable a short approval period for reinforcement to be delivered to site on time and the maximum re-use of previously ordered reinforcement from the now defunct design. This enabled us to achieve our deadline for the lowering of the East Abutment structure and did not impact the overall construction programme.

In addition to this, all structural steelwork for the temporary works was model, detailed and scheduled from Tekla by our fabrication department also enabling a comparison of geometry for the clash detection prior to installation.

May we please ask that you assist in bringing global recognition to this complex project and the hardworking team that delivered it, by casting your vote through the link below. Your vote could make the difference. Thank you.
